Beautiful VIC-20 board donated by the amazing @cmherndon79 for the 6560/1 project. This board will be the one that gets the prototype board for testing. #commodore #vicsrevenge

▸ May 20, 2022 ▸ Michael Doornbos ▸ 0 words

← Well that.. DEFINITELY looks like a Composite video signal (PAL). Woot! Now on to the interlace math and the NTSC version. Urg, do we REALLY need interlacing? VGA is SO much easier... #commodore #vicsrevenge I don’t think I can get away with NOT level shifting from 3.3 to 5v on a VIC-20. Probably not… But there sure are nice and cheap tools for things these days. Need a completely configurable 3 output 8khz to 160Mhz clock generator? That’ll be 6 whole dollars please. →
